model |
HEX-BLDC-005 |
|
hall sensor |
Without Holzer sensor |
|
Rated voltage |
1.8V~3.7V |
|
electric current |
No-load current: <0.1A, load current: 0.5A~1.2A |
|
Start-up time |
0.2s~0.3s |
|
speed |
No-load speed: 8400RPM, load speed: 7500RPM |
|
moment |
150g |
|
PCB size |
Outside diameter 4mm, inner diameter PCB 22mm built-in (size can be customized) |
|
Incidental function |
Over current protection, blocking protection, under voltage protection, CW\CCW, speed regulation function |
|
application area |
Lithium battery powered small power motor products, such as: hair, electric toothbrush, razor, electric knife, etc. |
Note: for the DC brushless motor control circuit parameters and functions have other requirements can be re customized
|
model |
HEX-BLDC-030 |
|
hall sensor |
Without Holzer sensor |
|
Rated voltage |
5.0V~12V |
|
electric current |
No-load current: <0.1A, load current: 0.5A~1.5A |
|
Start-up time |
0.2s~0.3s |
|
speed |
No-load speed: 6000RPM, load speed: 5000RPM |
|
moment |
150g |
|
PCB size |
Outside diameter 4mm, inner diameter PCB 22mm built-in (size can be customized) |
|
Incidental function |
Over current protection, blocking protection, under voltage protection, CW\CCW, speed regulation function |
|
application area |
Dry battery, lithium battery power supply of small power motor products, such as: hair, electric toothbrush, razor, electric push, etc. |
Note: for the DC brushless motor control circuit parameters and functions have other requirements can be re customized
